Container Dimensions

Container	Outside Length	Outside Height	Outside Width	Internal Length	Internal Height	Internal Width	Door Width	Door Height	Cubic Capacity	Max Gross Weight	Tare Weight
8ft Container	2.44m	2.26m	2.26m	2.29m	2.06m	2.11m	2.10m	1.95m	9.95m³	6,000kg	950kg
10ft Container	2.99m	2.59m	2.44m	2.84m	2.39m	2.35m	2.34m	2.28m	15.95m³	10,000kg	1,000kg
20ft Container	6.06m	2.60m	2.44m	5.9m	2.39m	2.35m	2.34m	2.28m	33.2m³	30,480kg	2,000kg
40ft Container	12.2m	2.60m	2.44m	12.03m	2.39m	2.35m	2.34m	2.28m	67.6m³	30,480kg	3,470kg
20ft Tunnel	6.06m	2.60m	2.44m	5.84m	2.39m	2.35m	2.34m	2.28m	32.8m³	30,480kg	2,180kg
20ft Open-sider	6.06m	2.60m	2.44m	5.9m	2.30m	2.29m	2.22m	2.19m	31m³	30,480kg	3,170kg
40ft High Cube	12.2m	2.90m	2.44m	12.03m	2.69m	2.35m	2.34m	2.58m	76.4m³	30,480kg	3,660kg
20ft Open-top	6.06m	2.90m	2.44m	5.96m	2.28m	2.35m	2.34m	2.28m	33m³	30,480kg	3,000kg
40ft Open-top	12.2m	2.60m	2.44m	12.03m	2.39m	2.35m	2.34m	2.28m	66.8m³	32,500kg	4,050kg
40ft Tunnel	12.2m	2.60m	2.44m	11.98m	2.39m	2.35m	2.34m	2.28m	67.4m³	30,480kg	3,680kg
40ft High Cube Open Sider	12.2m	2.90m	2.44m	12.03m	2.46m	2.28m	2.22m	2.35m	67.72m³	24,000kg	5,920kg
20ft High Cube	6.06m	2.90m	2.44m	5.96m	2.69m	2.35m	2.34m	2.58m	37.4m³	30,480kg	2,100kg

Contact us to discuss your container project.
